WELDABLE POWER FEEDTHROUGH, 4x MOLYBDENUM CONDUCTORS, 8A

Allectra SKU: 264-08MO500-4
WELDABLE POWER FEEDTHROUGH, 4x MOLYBDENUM CONDUCTORS, 8A

WELDABLE POWER FEEDTHROUGH, 4x MOLYBDENUM CONDUCTORS, 8A

Allectra SKU: 264-08MO500-4
Your inquiry was submitted successfully. You can expect to hear from us shortly.

Specifications

  • Vacuum Leak Rate UHV <5x10-10 mbar l/s
  • Size or DN Weld
  • Compliance Power feedthrough
  • Conductor Material MOLYBDENUM
  • Vacuum Seal ceramic
  • Body Material 304 Stainless steel
  • Voltage Rating 500 V DC
  • Max Current 8 Amps
  • Temperature Range -100°C to 450°C
