Vacuum socket 211-FS09-HV
Specifications
- Vacuum Leak Rate HV <1x10-8 mbar l/s
- Size or DN DN63 ISO-K flange
- Compliance Sub-D, DIN 41652, MIL-C-24308
- Pin Gender male
- Conductor Material NiFe (Au plated)
- Vacuum Seal Glass ceramic
- Body Material Stainless Steel 316L
- Voltage Rating 500V DC
- Max Current 5A per pin
- Temperature Range -200°C to 230°C
- Number of Pins 27
- Conductor Diameter 1mm
