Inclusions max 0.25mm2 /100cm3 (class 2)
Specifications
- Vacuum Leak Rate HV <1x10-8 mbar l/s
- Size or DN DN50KF flange
- Compliance KF TYPE ISO1609
- Vacuum Seal Viton O Ring
- Body Material Stainless Steel 304
- Temperature Range -100°C to 200°C
- Transmission >99.5%@ 193nm
- Inside Diameter 35mm
- Outside Diameter 75mm
- Parallelism <30 arc sec
- Surface Finish 40-20 Scratch-dig
- Optical Material UV Fused Silica grade F, 2D
- Optical Range 200-2000nm
