DN40CF POWER FEEDTHROUGH, 1000 AMPS, 1 COPPER TUBE CONDUCTOR, WATERCOOLED

Allectra SKU: 261-1000CU3K-C40
DN40CF POWER FEEDTHROUGH, 1000 AMPS, 1 COPPER TUBE CONDUCTOR, WATERCOOLED

DN40CF POWER FEEDTHROUGH, 1000 AMPS, 1 COPPER TUBE CONDUCTOR, WATERCOOLED

Allectra SKU: 261-1000CU3K-C40
Your inquiry was submitted successfully. You can expect to hear from us shortly.

Specifications

  • Vacuum Leak Rate UHV <5x10-10 mbar l/s
  • Size or DN DN40CF (2 ¾” OD flange)
  • Compliance Power feedthrough
  • Conductor Material COPPER
  • Body Material Stainless Steel/Ceramic
  • Voltage Rating 3 kV DC
  • Max Current 1000 Amps water cooled
  • Temperature Range -100°C to 450°C
  • Number of Pins 1
