Inclusions max 0.03mm2 /100cm3 (class 0)
Specifications
- Vacuum Leak Rate UHV <5x10-10 mbar l/s
- Size or DN DN40CF (2 ¾” OD flange)
- Compliance ISO 3669:2017
- Vacuum Seal Annealed Cu Gasket
- Body Material Stainless Steel 304
- Temperature Range -100°C to 200°C
- Inside Diameter 35mm
- Flatness λ/4 @632nm
- Coating Broadband AR Coating
- Parallelism <10 arc sec
- Surface Finish 20/10 Scratch/Dig
- Optical Material Fused Silica grade A, 3D
