DN25KF FLANGE WITH M12 FEEDTHROUGH SET, UHV & AIR SIDE CONNECTORS, 5m CABLE

DN25KF FLANGE WITH M12 FEEDTHROUGH SET, UHV & AIR SIDE CONNECTORS, 5m CABLE

Allectra SKU: 220-M12X4-SET-K25
Your inquiry was submitted successfully. You can expect to hear from us shortly.

DN25KF M12 SET, INCLUDES: 4-PIN FEEDTHROUGH, HIGH VACUUM CONNECTOR & VACUUM-COMPATIBLE CRIMP PINS, AND STRAIGHT AIR SIDE CONNECTOR WITH 5000mm OF CABLE.

Specifications

  • Vacuum Leak Rate HV <1x10-8 mbar l/s
  • Size or DN DN25KF flange
  • Compliance DIN EN61076-101
  • Body Material Ni plated Zn diecast
  • Voltage Rating 250V
  • Max Current 3Amp
  • Temperature Range -200oC to 120oC
  • Number of Pins 4
  • Num in Pack 1
