DN16CF ROTARY MOTION DRIVE, 38MM SHAFT LENGTH, 4.75MM SHAFT DIAMETER

Allectra SKU: ZRD93
DN16CF ROTARY MOTION DRIVE, 38MM SHAFT LENGTH, 4.75MM SHAFT DIAMETER

DN16CF ROTARY MOTION DRIVE, 38MM SHAFT LENGTH, 4.75MM SHAFT DIAMETER

Allectra SKU: ZRD93
Your inquiry was submitted successfully. You can expect to hear from us shortly.

• Torque 0.1Nm hand turned • Torque 0.01Nm at 300 rpm • Range of HV and UHV flanges • Fully bakeable to 250 °C standard, 400°C with actuator removed • Dimensionally compatible to other miniature drives • Thrust 16N

Specifications

  • Body Material Stainless Steel
  • Temperature Range 250°C
  • Shaft Diameter 4.75mm
  • Shaft Length 38mm
