DN16CF POWER FEEDTHROUGH, 2x STAINLESS STEEL CONDUCTORS, 1KV, 1A

<img class="lazyloaded" src="//nanovactech.com/cdn/shop/products/DN16CF_POWER_FEEDTHROUGH_2x_STAINLESS_STEEL_CONDUCTORS_1KV_1A-dc36-4d44-82f1-f3622157f4b5_800x.jpg?v=1718344416" alt="DN16CF POWER FEEDTHROUGH, 2x STAINLESS STEEL CONDUCTORS, 1KV, 1A">

Your inquiry was submitted successfully. You can expect to hear from us shortly.

Specifications

Vacuum Leak Rate UHV <5x10-10 mbar l/s
Size or DN DN16CF (1.33” OD flange)
Conductor Material Stainless steel
Vacuum Seal ceramic
Body Material 304 Stainless steel
Voltage Rating 1 kV DC
Max Current 1 Amp
Temperature Range -100°C to 450°C
