Leak Valve Manual 2 x Rotatable DN40CF

• Inlet pressure up to 10 bar to give high stability control • Fine control mechanism with minimum backlash • Adjustable graduated index ring • Wide dynamic range • Available with range of mounting flanges • User serviceable • 304L Stainless steel body and mallory sealing pad • Operating pressure range from 10-11 mbar • Bakeable to 450°C

Specifications

• Vacuum Leak Rate 1x10-12 mbar.l.s-1
• Size or DN DN40CF Rotatable
• Body Material 304L Stainless steel
• Temperature Range Open 450°C, Closed 250°C
• Conductance 0.1
• Dimension D 114mm
• Max. Inlet Pressure 10 bar
• Service Life 100,000 Cycles
