The K6 chiller takes the cooling capacity up to 6kW. These are whisper quiet with state of the art dual display microprocessor PID controller for unrivalled temperature control.
Features & Benefits
- Compact robust design
- Powerful 6000W Cooling Capacity (@17C set point)
- Full temperature control
- Versatile flow rates and pressures
- 2 Year parts, 1 year labour warranty. Optional 3 years comprehensive
Specifications
| Dimensions LxWxH | 775 x 510 x 850 mm |
| Cooling capacity (water @ 17C) | 6000 Watts |
| Digital temperature display | Dual readout as standard (set point and indicated temperature) |
| Temperature range | +4C to +35C (low temp version down to -30C) |
| Temperature Stability | +/- 0.1C |
| PID Temperature control | Microprocessor control, easy front panel programming, with auto-tune, fuzzy logic. |
| Temperature alarm | Adjustable high/low |
| Low fluid level & flow alarm | Visual |
| System volume | 7.0 litres |
| Compatible fluids | Hexid fluids/water/propylene glycol |
| Fluid connections | BSP threaded Male 3/4", Female 1/2". 3/8" and 1/2" barbs also supplied |
| Compressor overload protection | Standard |
| Emergency Off (EMO) | Main Circuit Breaker |
| Noise Level | 68 dB(A) @ 1 metre |
| Weight | 125kg |
| Power requirements | 12 Amps, 1ph, 230V 50Hz |
| Warranty | 2 years parts, one year labour. Optional 3 year comprehensive |
